SIP User's Manual 54 Document #: LTRT-65415
MediaPack Series
The table below describes the areas of the 'Home' page.
Table 3-3: Description of the Areas of the Home Page
Label Description
Alarms
Displays the highest severity of an active alarm raised (if any) by the device:

Green = no alarms

Red = Critical alarm

Orange = Major alarm

Yellow = Minor alarm
To view a list of active alarms in the 'Active Alarms' page (see "Viewing
Active Alarms" on page 183), click the A
larms area.
Channel/Ports
Displays the status of the ports (channels):

(red): line not connected (only applicable to FXO devices)

(grey): channel inactive

(blue): handset is off-hook

(green): active RTP stream
You can also view the channel's port settings (see "Viewing Analog Port
Information" on page 56),
reset the port (see "Resetting an Analog Channel"
on page 55),
and assign a name to the port (see "Assigning a Port Name" on
page 55).
Uplink (MP-11x)
LAN (MP-124
If clicked, the 'Ethernet Port Information' page opens, displaying Ethernet
port configuration settings (see "Viewing Ethernet Port Information" on page
182).
Fail
Currently not supported.
Ready
Currently not supported.
Power
Always lit green, indicating power received by the device.
