2. CNC Monitor Screen
2.4 Parameters
I - 96
2.4.2 Setup Parameters
Pressing the menu [SET UP] displays the OPEN SETUP PARAM screen.
The system's basic parameters are normally hidden as setup parameters to prevent mistaken operations
and to simplify the display.
The setup parameters can be displayed and set by making a declaration to open the setup parameters on
this screen.
1) Select the setup parameter.
Key-in "Y" in # ( ), and then press [INPUT].
The normally hidden setup parameter menu will display when the menu changes over.
The required menu can be selected to display and set the setup parameters.
2) Cancel the setup parameter selection.
Key-in "N" in # ( ), and then press [INPUT].
The setup parameter menu will disappear.
(Note) The setup parameters are not displayed when the power is turned on.
Refer to “Setup Manual” for details on the setup parameters.
Always turn the power OFF after selecting the setup parameters.
