III - 62
7. Data Backup and Restoration
7.1 GOT Data Backup and Reinstallation
7. Data Backup and Restoration
7.1 GOT Data Backup and Reinstallation
Standard functions (standard monitor OS), communication driver, BootOS and projects in GOT can be
backed up in batch to the CF card inserted in GOT.
The data backed up in batch can be reinstalled to GOT in easy operation.
(Note 1) See below for the procedure when OS data and project data (drawing data) are stored in "C Drive".
If OS data and project data (drawing data) are installed in "A Drive (CF card)", backup data from the
CF card.
(Note 2) When using GOT1000 series GT16, USB memory is also available for backup and reinstallation.
7.1.1 Backup procedures
(1) Set "OFF" the CF Card access switch.
(2) Insert the CF Card into the card slot.
(3) Set "ON" the CF Card access switch.
(4) Open the GOT Utility screen.
For GT15: Press the right and left top corners together.
For GT16: Press the left top corner.
To Next Page
