Appendix 3. List of Command Value Ranges
Item Command value range
Minimum input setting unit 0.001
Maximum stroke
(value on machine coordinate system)
±99999.999mm
Maximum command value ±99999.999mm
Rapid traverse rate 1 to 1000000mm/min
Cutting feed rate 1 to 1000000mm/min
2nd zero point offset
(value on machine coordinate system)
±99999.999mm
Tool offset amount (tool dimension) ±999.999mm
Tool offset amount (wear) ±99.999mm
Handle feed amount 0.001mm/P
Soft limit range
(value on machine coordinate system)
±99999.999mm
Dwell time 0 to 99999.999s
Backlash compensation amount 0 to ±511 pulses
Screw lead 0.0001 to 99.999999mm
Synchronous feed 0.001 to 99.999mm/rev
