1. Setting and Display Unit
1.2 Screen Operation of GOT
I - 2
1.2 Screen Operation of GOT
Using GOT enables the NC screen as follows.
"CNC Monitor"
icon
Exit
Exit
Extended function switch
(to CNC monitor)
(Note 1)
(a)
(b)
<GT15>
<GT16>
Extended function switch
(to CNC monitor)
Monitor screen
(Note) Refer to “2.1.2 Screen Transition Diagram (L system)” (Refer to 2.1.3 for M system.) for details.
NC screen appears by either method.
(a) Select “CNC monitor” key on Utility screen.
(b) Select the extended function switch (to CNC Monitor) (Note 1) on Monitor screen.
(Note 1) This switch differs depending on the machine. Refer to the instruction manual issued by the
machine tool builder.
To Next Page
