Appendix 6. Operation Messages on Setting Display Unit
Appendix 6.1 Operation Errors
IV - 23
Appendix 6. Operation Messages on Setting Display Unit
If a setting operation error occurs only any of the setting and display unit's screens, the error No. E{{ and
a message indicating the details will appear.
Appendix 6.1 Operation Errors
Δ: Message requiring resetting and restarting
×: Message requiring restarting after canceling error conditions
(The bold characters are the messages displayed on the screen.)
Error No. Error message Details
E01 SETTING ERROR
Δ
• The setting data is incorrect. An alphabetic character was set
when only number can be set‚ etc.
• Data was input without setting number (#).
(Word editing)
• Even though no retrieval data was set, menu key "Word↓"
/"Word↑", or "STR.↓"/"STR.↑" was pressed.
• Even though no data is stored in edit buffers, menu key
"Replace" was pressed.
• One of the following characters was entered as the first
character of the retrieval data and edit buffers: 0 to 9, ".", " "
(space), "+", "−", "=", "*", "[", and "]".
• When the incremental detection system was used, the
parameter (#0 INIT SET) was set on the absolute position
setting screen.
• The data input for the standard parameter setting or during
execution of formatting is not "Y" or "N".
• A value from 4 to 10 was specified for "#1043 lang".
• Even though no language data exists, its output and
comparison were attempted. Check the numbers (O253 and
O254) of the language data to be output.
E02 DATA OVER
Δ
• The setting data exceeded the setting range.
• The compensation data specification exceeded the range when
inputting the tool offset data on tape‚ so that block could not be
input. Press the INPUT key again while the input screen is
displayed‚ and the input will continue from the next block.
• When work coordinate offsets are measured, the calculation
results given by pressing the CALC key are exceeding the
specified range. Correctly specify the tool length or the
abrasion data of cutting edges used for the calculation.
• When there was no option, 2 or more was specified for "#1043
lang". Otherwise, an option was added and 16 or more was
specified for "#1043 lang".
E03 No. NOT FOUND
Δ
• The corresponding setting No. (#) was not found. This error
occurs if a setting No. not found on the screen was set and
input‚ or if a variable No. not found in the specifications was set
and input for the common variables.
• When the tool length was measured manually, a nonexisting
tool wear compensation number was specified and the sensor
was turned on. Specify the R register of the offset number
correctly.
To Next Page
