2. CNC Monitor Screen
2.5 Program
I - 101
2.5.3.1 MDI Screen Menu Function
(1)
Menu when [MDI] is selected (Only when "#1139 Edtype" is set to "0".)
Menu Function
[MDI]
Reverse display of MDI menu means that MDI screen is selected. MDI data can be set on
the MDI screen.
[EDIT] Use this key to change the MDI screen to the EDIT screen.
(2) MDI screen extension operation menu
Menu Function
MDI-ENT MDI data can be registered in memory as a machining program.
Extension operation menu is also highlighted when it is selected. When one extension operation menu
is selected, its corresponding extension operation is enabled and MDI data cannot be set. When no
extension operation menu is selected, MDI data can be set.
When an extension operation menu key is once pressed, the extension operation menu is selected.
When the key is again pressed, the extension operation menu is unselected. At normal completion of
setting processing, automatically it becomes unselected.
To Next Page
