Appendix 1. Registering and Editing Fixed Cycle Programs
Appendix 1.5 Standard Fixed Cycle Subprogram
IV - 2
Appendix 1.5 Standard Fixed Cycle Subprogram
(1) Lathe specifications
G37 Automatic tool length measurement G74 End face cutoff pattern cycle
O370 AUTO-TLM O740 FACE-PATC
G31Z#5F#3
IF[ROUND[ABS[#2-[##10*#11-#12]]]GT#8]GOTO
1
IF[ROUND[##10*#11-#12]EQ#4]GOTO1
##9=##10-#12/#11-#2/#11+##9
#3003=#1
N2
M99
N1#3901=126
G.1
IF[ABS[#2]GT0]GOTO10
#14=1
N10#13=#3
IF[#15NE0]GOTO11
#13=#3-#5
N11#16=0
DO1
#10=0
#11=#4
DO2
#10=#10+#4
IF[ABS[#10]GE[ABS[#1]]]GOTO1
G01X#11
G00X#6
#11=#4-#6
END2
N1G01X#1-#10+#11
IF[#15EQ0]GOTO20
IF[#16EQ0]GOTO21
N20G00Y#5
N21#16=1
G00X-#1
IF[#14]GOTO3
#12=#12+#3
IF[ABS[#12]LT[ABS[#2]]]GOTO2
#14=1
#13=#2-#12+#13
N2G00Y#13
#13=#3-#5
END1
N3G00Y-#2-#5
M99
