ENGINE AND EMISSION CONTROL SYSTEM (RHZ ENGINE) 6E3-5
1. Fuel tank
2. Fuel pump
3. Fuel filter
4. Fuel temperature sensor
5. Injection pump
6. Common rail
(High pressure fuel injection rail)
7. Injector
8. Fuel heater
: Fuel feed line
: Fuel return line
FUEL DELIVERY SYSTEM
