7B1-104 AUTOMATIC TRANSMISSION (4 A / T)
1. Valve body assembly
2. Manual valve
3. Detent spring
4. Detent spring cover
5. Shift solenoid-B (No.2) valve
6. O-ring
7. TCC (lock-up) solenoid valve
8. Pressure control solenoid valve
9. Clamp
10. Shift solenoid-A (No.1) valve
: Apply automatic transmission fluid.
: Tightening torque.
: Do not reuse.
9
VALVE BODY ASSEMBLY
CAUTION:
When replacing pressure control solenoid valve (8), it is strictly required to replace it together with valve
body assembly (1) as a set.
