MANUAL TRANSMISSION 7A2-41
INPUT SHAFT BEARING RETAINER AND OIL SEAL
Install new oil seal (2) to bearing retainer (1) by using special tool
as shown in the figure.
Apply grease to oil seal lip.
Grease: 99000-25010
Special tool
(A): 09913-75821
(B): 09924-84510-004
TRANSIMISSION REAR CASE
1) Check that interlock cam component (1) moves smoothly in both
turning direction and sliding direction.
2) Insert interlock cam component (1) to rear case (2).
3) Set interlock cam component (1) as shown in the figure and drive
pin by using special tool.
Special tool
(A): 09922-85811
