4B-2 PROPELLER SHAFTS
ON-VEHICLE SERVICE
PROPELLER SHAFT
INSTALLATION
Reverse removal procedure to install propeller shaft.
D Use following specification to torque universal joint flange bolts
and nuts.
Tightening Torque
Front propeller shaft flange nuts:
50 N
.
m (5.0 kg-m, 36.5 lb-ft)
Rear propeller shaft flange bolts (a):
60 N
.
m (6.0 kg-m, 43.5 lb-ft)
D When installing propeller shaft, align the match marks.
Otherwise, vibration may occur during driving.
NOTE:
If transfer oil was drained for front propeller shaft removal,
pour specified gear oil into transfer case to specified level.
TIGHTENING TORQUE SPECIFICATION
To Next Page
