7A2-26 MANUAL TRANSMISSION
INPUT SHAFT ASSEMBLY
Remove circlip of input shaft (1) and pull out bearing (2) with puller
(3) and press.
CAUTION:
Sealed bearing must not be washed.
MAIN SHAFT ASSEMBLY
1) Pull out needle bush (1), needle bearing (2), main shaft bearing
(3) and low gear (4) together by using puller (5) and press (6).
2) Remove low gear synchronizer ring (2) and ball (1).
3) Pull out 2nd gear (2), needle bearing, 2nd gear synchronizer out-
er ring, cone ring, inner ring and low speed synchronizer
sleeve/hub assembly (1) together by using puller (3) and press
(4).
