8G
IMMOBILIZER CONTROL SYSTEM (IF EQUIPPED) 8G-1
GENERAL DESCRIPTION 8G- 2. . . . . . . . . . . . . .
Ignition Key 8G- 4. . . . . . . . . . . . . . . . . . . . . . . . . .
Coil Antenna 8G- 4. . . . . . . . . . . . . . . . . . . . . . . . .
Immobilizer Control Module 8G- 4. . . . . . . . . . . .
ECM 8G- 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On-board Diagnostic System
(Self-diagnosis function) 8G- 5. . . . . . . . . . . . . .
DIAGNOSIS 8G- 6. . . . . . . . . . . . . . . . . . . . . . . . . . .
Precautions in Diagnosing Troubles 8G- 6. . . . .
Immobilizer Diagnostic Flow Table 8G- 7. . . . . .
Diagnostic Trouble Code (DTC) Check
(Immobilizer Control Module) 8G- 8. . . . . . . . .
Diagnostic Trouble Code Table 8G- 9. . . . . . . . .
TABLE A Scan Tool Can Not
Communicate with Immobilizer
Control Module 8G-10. . . . . . . . . . . . . . . . . . . . . .
DTC11 Transponder Code Not
Matched 8G-11. . . . . . . . . . . . . . . . . . . . . . . . . . .
DTC31 Transponder Code Not
Registered 8G-11. . . . . . . . . . . . . . . . . . . . . . . . .
DTC12 Fault in Immobilizer Control
Module 8G-11. . . . . . . . . . . . . . . . . . . . . . . . . . . .
DTC13 No Transponder Code
Transmitted from Ignition Key 8G-12. . . . . . . . .
DTC14 Coil Antenna Circuit Malfunction 8G-12.
DTC41 ECM Not Registered 8G-13. . . . . . . . . . .
DTC42 Serial Data Circuit Malfunction 8G-14. .
DTC43 ECU Code Not Matched 8G-15. . . . . . . .
Inspection of Immobilizer Control Module
and Its Circuit 8G-16. . . . . . . . . . . . . . . . . . . . . . .
Voltage Check 8G-16. . . . . . . . . . . . . . . . . . . . . . .
Resistance Check 8G-17. . . . . . . . . . . . . . . . . . . .
ON-VEHICLE SERVICE 8G-18. . . . . . . . . . . . . . . .
Precautions in Handling Immobilizer
Control System 8G-18. . . . . . . . . . . . . . . . . . . . .
Immobilizer Control Module 8G-19. . . . . . . . . . . .
Coil Antenna 8G-19. . . . . . . . . . . . . . . . . . . . . . . . .
HOW TO REGISTER IGNITION KEY 8G-20. . . . .
PROCEDURE AFTER IMMOBILIZER
CONTROL MODULE REPLACEMENT 8G-21. .
PROCEDURE AFTER ECM
REPLACEMENT 8G-22. . . . . . . . . . . . . . . . . . . . . .
SPECIAL TOOLS 8G-23. . . . . . . . . . . . . . . . . . . . . .
SECTION 8G
IMMOBILIZER CONTROL SYSTEM
(IF EQUIPPED)
WARNING:
For vehicles equipped with Supplemental Restraint (Air Bag) System:
D Service on and around the air bag system components or wiring must be performed only by an autho-
rized SUZUKI dealer. Refer to “Air Bag System Components and Wiring Location View” under “Gener-
al Description” in air bag system section in order to confirm whether you are performing service on
or near the air bag system components or wiring. Please observe all WARNINGS and “Service Precau-
tions” under “On-Vehicle Service” in air bag system section before performing service on or around
the air bag system components or wiring. Failure to follow WARNINGS could result in unintentional
activation of the system or could render the system inoperative. Either of these two conditions may
result in severe injury.
D Technical service work must be started at least 90 seconds after the ignition switch is turned to the
“LOCK” position and the negative cable is disconnected from the battery. Otherwise, the system may
be activated by reserve energy in the Sensing and Diagnostic Module (SDM).
