7B1-66 AUTOMATIC TRANSMISSION (4 A / T)
INPUT SHAFT SPEED SENSOR
INSPECTION
Check input shaft speed sensor (1) for resistance between termi-
nals of sensor or TCM connector.
Input shaft speed sensor resistance:
560 – 680 Ω (at 20_C (68_F))
OUTPUT SHAFT SPEED SENSOR
INSPECTION
Check output shaft speed sensor (1) for resistance between termi-
nals of sensor or TCM connector.
Output shaft speed sensor resistance:
387 – 473 Ω (at 20_C (68_F))
O/D OFF SWITCH
INSPECTION
Check O/D off switch for operation referring to step 4 of “DIAG-
NOSTIC FLOW TABLE B-2” in this section.
If malfunction is found, replace.
