6-12 ENGINE DIAGNOSIS (RHZ ENGINE WITH SINGLE-CONNECTOR ECM)
CUSTOMER PROBLEM INSPECTION FORM (EXAMPLE)
User name: Model: VIN:
Date of issue: Date Reg. Date of problem: Mileage:
PROBLEM SYMPTOMS
VDifficult Starting VPoor Driveability
VNo cranking
VNo initial combustion
VPoor starting at (VCold/VWarm/VAlways)
VOther ______________
VHesitation on acceleration
VBack fire/After fire
VLoss of power
VSurging
VAbnormal knocking
VOther ______________
VPoor Idling VEngine Stall when
VPoor fast idle
VAbnormal idling speed (V High VLow) ( r/min.)
VUnstable
VHunting ( r/min. to r/min.)
VOther ______________
VImmediately after start
VAccel. pedal is depressed
VAccel. pedal is released
VLoad is applied VA/C VElectrical load VP/S
VOther _____________
VOTHERS:
VEHICLE/ENVIRONMENTAL CONDITION WHEN PROBLEM OCCURS
Environmental Condition
Weather
Temperature
Frequency
Road
VFair VCloudy VRain VSnow VAlways VOther ______________ ( _F/ _C)
VHot VWarm VCool VCold VAlways
VAlways VSometimes ( times/ day, month) VOnly once VUnder certain condition
VUrban VSuburbs VHighways VMountainous (VUphill VDownhill) VPaved road VGravel
VOther ______________
Vehicle Condition
Engine
condition
VCold VWarming up phase VWarmed up VAlways V Other at starting VImmediately after start/
VRacing without load VEngine speed ( r/min.)
Vehicle
condition
VDuring driving: VConstant speed ( km/h, mile/h) VAccelerating VDecelerating VRight hand corner
VLeft hand corner VWhen shifting (Lever position ) VAt stop VOther ( )
Malfunction
indicator lamp
condition
VAlways ON VSometimes ON VAlways OFF VGood condition VFlashing
Diagnostic trouble code
First check: VNo code VMalfunction code ( )
Diagnostic
trouble
code
Second check: VNo code VMalfunction code ( )
NOTE:
The above form is standard sample. It should be modified according to conditions characteristic of each
market.
