7B1-84 AUTOMATIC TRANSMISSION (4 A / T)
: Do not reuse.
: Apply automatic
transmission fluid.
1. Sealing
2. Bearing
3. Bearing race
4. O / D case
5. Planetary ring gear
6. O-ring
7. Brake piston
8. Return spring
9. Retainer
10. Retaining ring
11. Cushion plate
12. Brake backing plate
13. Brake disc
14. Brake plate
15. Thrust race
SUB-ASSEMBLY REPAIR
OVERDRIVE (CASE SIDE)
