6G-10 CRANKING SYSTEM
SPECIFICATIONS
2.0 kW Reduction Type
Voltage 12 volts
Output 2.0 kW
Rating 30 seconds
Direction of rotation Clockwise as viewed from pinion side
Brush length 18.0 mm (0.71 in.)
Number of pinion teeth 10
Performance Condition Guarantee
No load characteristic 11.0 V
130 A maximum
3,600 rpm minimum
Around
at 20 _C
Load characteristic
7.7 V
400 A
10.6 N
.
m (1.06 kg-m, 7.67 lb-ft) minimum
1,280 rpm minimum
(68 _F)
Locked characteristic 3.0 V
1000 A maximum
29.4 N
.
m (2.94 kg-m, 21.3 lb-ft) minimum
Magnetic switch operating voltage 8 volts maximum
REQUIRED SERVICE MATERIAL
MATERIAL
RECOMMENDED
SUZUKI PRODUCT
USE
Lithium grease
SUZUKI SUPER GREASE A
(99000-25010)
D Front bush
D Plunger
D Pinion drive lever
D Internal gear
D Planetary carrier shaft
D Planetary gear
D Ball
TIGHTENING TORQUE SPECIFICATIONS
N
.
m kg-m lb-ft
Starting motor mounting bolt 45 4.5 32.5
“B” terminal nut 11 1.1 8
Magnetic switch screw 7 0.7 5.0
Starting motor housing screw 11 1.1 8
