6-18 ENGINE DIAGNOSIS (RHZ ENGINE WITH SINGLE-CONNECTOR ECM)

Operation

VISUAL INSPECTION

Visually check following parts and systems.

INSPECTION ITEM

REFERRING SECTION

D Engine oil – – – – – level, leakage

D Engine coolant – – – – – level, leakage

D Fuel – – – – – level, leakage

D A/T fluid – – – – – level, leakage

D Air cleaner element – – – – – dirt, clogging

D Battery – – – – – fluid level, corrosion of terminal

D Drive belt – – – – – tension, damage

D Accelerator cable – – – – – play (after warm up engine), installation

D Vacuum hoses of air intake system – – – – – disconnection, looseness,

deterioration, bend

D Connectors of electric wire harness – – – disconnection, friction

D Fuses – – – – – burning

D Parts – – – – – installation, bolt – – – – – looseness

D Parts – – – – – deformation

D Other parts that can be checked visually

Also add following items at engine start, if possible.

D Malfunction indicator lamp

D Charge warning lamp

D Engine oil pressure warning lamp

D Engine coolant temp. warning lamp

D Engine coolant temp. meter

D Fuel level meter

D Abnormal air being inhaled from air intake system

D Exhaust system – – – – – leakage of exhaust gas, noise

D Other parts that can be checked visually

Section 0B

Section 6E3

Section 8

Section 6

Section 6H

Section 8
