Trends/data dialogs
164 Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n
Special characters and symbols
In addition to parameters, certain conditions, such
as disconnected leads, artifact, and so on, are also
identified on graphical and tabular trends.
Graphical trends
A graphical trend plots the behavior of parameters
over time. Graphical trends are continuously
updated, with the most recent data appearing on
the right side of the screen. The Trends/Data
dialog consists of the following graphical trend
pages:
– Graph page
– Graph vitals page
– Ventilation / Anesthesia page
All graphical trend pages look almost identical. In
the Graph and the Ventilation / Anesthesia pages
you can change the parameter content.
However, the Graph vitals is a pre-configured
display consisting of the following set of commonly
trended parameters which are displayed in four
graphical windows:
To access the graphical trend pages
1 Select the Trends/ Data... button on the main
menu bar.
2 Select the Trends tab (if not already selected).
3 Select one of the following graphical trend
pages:
– Graph tab to view general trends
– Graph vitals tab to view a set of
pre-configured parameters
– Ventilation / Anesthesia tab to view
ventilation/anesthesia-related parameters
– BIS tab to view BIS trends
Event Character/symbol
Asystole ASY
Ventricular fibrillation VF
Apnea Apnea
No parameter values are
available
* * *
Out of range value +++ (high) - - - (low)
Relearning LEARN
Interruption in power or
monitor is placed into
standby
No values
Window 1 (top) HR, SpO2, and RRi
Window 2 NIBP
Window 3 Ta, Tb
Window 4 CO
2
