Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 177
Trends/data dialogs
Data review pages
In addition to trend data, the Trends/Data dialog
also provides several data review pages which are
outlined in the following table. Some of these
review pages are also available under different
tabs.
To access the data reviews
1 Select the Trends/ Data... button on the main
menu bar.
2 Select one of the following tabs to access the
desired data:
Trends, ECG, Ventilator or Anesthesia/
Ventilation, Hemo, Labs, Reports
NOTE
The horizontal tab Ventilator changes to
Anesthesia/ Ventilation when a anesthesia
machine is connected.
Data review page Description Available functions
Show all page under the
ECG tab
This page shows the
waveforms of all connected
leads along with the scale
and the waveform label.
– Print button for requesting a Rest ECG
report
– Print button for requesting an ECG report
ST complex page under
the ECG tab
This page shows the ST
complexes. The number of
displayed ST complexes
depends on the connected
lead set.
– Print button for generating an ST report
– ST button
– Reference on/off button for displaying
reference complexes
– ISO button
– Relearn button
