Trends/data dialogs
The layout of the tabular trend
The following diagram shows the tabular trend
page. Configuring the tabular trend page also
determines how the information appears on the
tabular trend report.
A Trends tab
B Parameter label column
C Parameter columns
D Latest trend data
E Graph tab (see page 169)
F Table tab
G Graph vitals tab (see page 169)
H Anesthesia workstation tab accesses the
tabular trends of a set of pre-configured trend
parameters for critical care or anesthesia
ventilation.
I BIS tab for accessing the tabular BIS trends
J Scroll keys and scroll bar
K Print button
L Setup button for selecting which parameters
are displayed and in what priority
M View button for selecting how much time is
displayed
024
Trends/Data
A
B
E
F
G
CCCD
J
K
H
I
L
J
M
