Dräger Infinity M540 User Manual

Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 353
Microstream CO
2 monitoring
Using the CO2 dialog box
Setup for CO2 parameters takes place in the CO2
dialog. This dialog contains the following tabs:
–Mainstream sets associated CO2 parameters
– Microstream sets associated CO
2 parameters
– Calibration check performs a
Microstream MCable calibration. For
information about the Calibration Check tab,
see "Calibration Check" on page 355.
If the Cockpit is not set up for CO2 monitoring, then
the Mainstream tab also displays in the CO2
dialog.
To access the Microstream settings
If the CO
2 parameter displays on the Cockpit:
1 Touch the CO
2 parameter field.
2 Touch the Microstream tab.
Or, if the CO
2 parameter field is not displayed:
 Select Sensor parameters... from the main
menu bar > Microstream tab to access the
Microstream page. If you cannot see the tab,
select the following two symbols located in the
upper right corner of the dialog: symbol and
the display filter button.
CO2 limits
Setup functions for CO2 parameters take place in
the Microstream tab within the CO2 dialog.
The Microstream tab displays fields on the upper
left side of the window for etCO2, inCO2, and RRc
settings.
etCO2 and RRc allow adjustment of the upper and
lower alarm limits, use of the Archive feature, and
use of Auto set. For inspiratory CO2, only the
upper limit and Archive can be used.
NOTE
CO2 limits settings apply to both Mainstream and
Microstream.
