Operating concept
74 Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n
27 Vent
28 O
2 (MEDIBUS.X)
29 Agent (MEDIBUS.X)
30 BIS (not available in neonate mode)
31 NMT
32 CO-Ox
Views
Each Cockpit supports eight pre-configured Dräger
views and, as an option, up to eight custom views.
Views control the content and appearance of the
screen.
To adjust the screen layout to the needs of the
current monitoring session, switch to a different
view.
Views can be shared among various profiles which
are pre-configured setups. This sharing of views
eliminates time-consuming setup tasks. Views can
be assigned to each profile (see page 488).
Selecting a view
Reconfigure the screen by selecting a different
view.
To select a view
1 Select the Views... button on the main menu
bar.
2 Select the Views tab if it is not already selected
to open a popup with pre-configured views.
3 Select the desired view from the Custom views
(option) or the Draeger views pick lists.
The monitoring area is configured accordingly.
The view editor
The view editor (option) allows authorized
personnel to create and modify customized views.
Dräger views cannot be modified. Access to the
view editor is password-protected. For more
information, see page 456.
