Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 229
ECG, arrhythmia, and ST segment
Reviewing ST complexes
You can view all ST complexes or zoom in on a
single complex.
The following functions are available in either view:
– Changing the isoelectric point
– Changing the ST measuring point
– Relearning the QRS morphology
– Saving a reference complex
– Requesting an ST report
In all trends, a solid white vertical line on the ST
graphical trends marks changes in ST measuring
points along with a time stamp.
Reviewing all ST complexes
The following diagram shows the ST complex
page. The number of displayed ST complexes
depends on the connected lead set.
A ECG tab
B ST complex tab
C Save reference button
D Print button for generating an ST report
E ST button
F Reference on/off button
G ISO button
H Relearn button
I ST panels for each monitored ST lead
(including waveform scale, ST measuring point,
isoelectric point, and reference point)
J ST label (unique for each ST lead)
To access ST complexes
Select the heart rate parameter field to select
the ECG page directly.
or
1 Select Sensor parameters... from the main
menu bar.
2 Select the ECG tab to access the ECG page.
3 Select the ECG tab (if not already selected).
4 Select the ST complex tab (if not already
selected).
