External devices – MEDIBUS.X devices
418 Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n
CO2 setup functions
See page 414 for information on how to access this
page. The tab is labelled CO2 when a ventilator is
connected. The tab is labelled CO
2/O2/ Agent
when an anesthesia workstation is connected.
Selection Available settings Description
Menu selections when Ventilator tab is selected.
CO
2 Scale – 0 to 40 (default), 0 to 60, 0 to 80,
0 to 100 mmHg
– 0.0 to 5.0 (default), 0.0 to 8.0, 0.0 to 12.0,
0.0 to 16.0 kPa
– 0 to 5 (default), 0 to 8, 0 to 12, 0 to 16%
Determines the scale of the
displayed CO2 waveform.
Color Red, green, blue, yellow (default), light blue,
purple, orange, white.
Determines the color of the CO2
parameter field and waveform.
Menu selections when Anesthesia workstation tab is selected.
etCO2 parameter
field
–etCO2 (default)
– etCO2/O2
Determines the appearance of
the etCO
2 parameter field.
CO2 Scale – 0 to 40 (default), 0 to 60, 0 to 80,
0 to 100 mmHg
– 0.0 to 5.0 (default), 0.0 to 8.0, 0.0 to 12.0,
0.0 to 16.0 kPa
– 0 to 5 (default), 0 to 8, 0 to 12, 0 to 16%
Determines the scale of the
displayed CO2 waveform.
Color Red, green, blue, yellow (default), light blue,
purple, orange, white.
Determines the color of the CO2
parameter field and waveform.
O2 parameter
field
–O2
–O2/N2O (default)
–Off
Determines the appearance of
the O
2 parameter field.
Agent parameter
field
–Agent
– Agent/ xMAC (default)
–Agent/N2O
–Off
Determines the appearance of
the Agent parameter field.
Note: If two agents are
detected, both are displayed
automatically.
