Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 319
Invasive blood pressure (IBP)
Accessing the invasive blood pressure settings
Select the IBP parameter field to select the IBP
page directly.
or
Select Sensor parameters... from the main
menu bar > IBP tab to access the IBP page. If
you cannot see the tab, select the following two
symbols located in the upper right corner of the
dialog: symbol and the display filter
button.
The top portion of the page contains the Auto set
and Alarm buttons for configuring the alarm
functions. For detailed alarm setup information, see
"Configuring the alarm settings for a patient" on
page 125.
Invasive blood pressure parameter setup functions
All invasive blood pressure setup functions take
place in the IBP page (see page 319).
Selection Available settings Description
Zero None Zeroes only the pressure indicated on
the IBP page and displays the time and
date of the last zeroing (see page 313).
Label ART, PA, CVP, LA, LV, RV, RA, ICP, GP1 to
GP4.
The defaults are as follows:
– Channel 1: GP1
– Channel 2: GP2
– Channel 3: GP3
– Channel 4: GP4
Allows you to assign a label to each
pressure channel.
Scale – 5, 10, 15, 20, 25, 30, 35, 40, 50, 75, 100,
125, 150, 175, 200, 225, 250, 300 mmHg
– 1, 2, 3, 4, 5, 6, 8, 10, 12, 14, 16, 18, 20,
24, 30, 32, 36, 40 kPa
– GP1 to 4, ART, LV:
200 mmHg (30 kPa) for adults
150 mmHg (20 kPa) for pediatrics
100 mmHg (16 kPa) for neonates
– PA, RV: 50 mmHg (12 kPa)
– ICP, CVP, LA, RA: 20 mmHg (4 kPa)
Controls the upper scale of the pressure
waveform.
The lower scale value is either
–5 mmHg (–0.7 kPa) for pressures
labeled CVP, RA, LA or 0 mmHg (0 kPa)
for other pressure labels.
