Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 363
Scio Monitoring
O2 alarm limits
For gas analyzers with O2 monitoring, the O2 tab
displays fields on the upper left side of the window
for etO2
and FiO2 alarm limit settings.
etO2 and FiO2 allow adjustment of the upper and
lower alarm limits, use of the Archive feature, and
use of Auto set.
O2 parameter setup functions
Setup functions for O2 parameters take place in the
O
2 tab within the Scio dialog.
NOTE
When a gas analyzer without O2 monitoring is
connected, the controls for O
2 alarms are not
available in the Scio setup menu.
Selection Available settings Description
Parameter field – O
2
–O2/N2O
Configures the O
2 display based on the
selected setting.
Scale [%] –0-100
– 15-35
– 20-100 (default)
– 25-45
– 35-55
– 45-65
– 55-75
– 65-85
– 75-95
– 85-105
Adjusts the size of the O
2 waveform.
Mini-trend – etO2
(default)
– FiO2
Selects the parameter to display in the mini-
trend associated with the O
2 parameter field.
