Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 207
ECG, arrhythmia, and ST segment
ECG colors
Lead wire connectors to the electrodes are labeled
and color-coded according to IEC and AHA.
IEC AHA/US
L Yellow LA Black
F Green LL Red
R Red RA White
C/C2 White/white and yellow V/V2 Brown/brown and yellow
N Black RL Green
C+/C5 Gray and white/white and black V+/V5 Gray and brown/brown and orange
C6 White and violet V6 Brown and violet
C4 White and brown V4 Brown and blue
C3 White and green V3 Brown and green
C1 White and red V1 Brown and red
