Operating concept
Main menu bar and quick access toolbar
The following diagram shows the main menu bar
with the quick access symbols and a quick-access
toolbar. The main menu bar and the quick-access
symbols are located along the right edge of the
screen and are always visible. The quick-access
toolbars remain visible after the user selects the
corresponding quick access symbol.
A Quick access symbols
B Main menu bar buttons
C Quick access toolbar
Main menu bar
The content of the main menu bar can be
customized. By adding and removing buttons, the
menu bar can contain the most frequently used
buttons. However, several buttons with essential
functionality are permanently placed on the menu
bar and cannot be moved. This key configuration
becomes part of a profile. For more information,
see page 452.
The following buttons appear on the main menu
bar.
011
B
B
B
B
B
B
B
B
A
C
Alarms... Opens the Alarms dialog.
Mark event Stores an event in the alarm
history.
Code Executes pre-configured
functions during an emergency.
Views... Opens the Views dialog.
Print screen
1)
Prints the contents of the
current screen on a connected
laser printer.
Freeze
waveforms
Stops all waveforms for
60 seconds.
Trends/ Data... Opens the Trends/Data dialog.
Procedures... Opens the Procedures dialog.
Sensor
parameters...
Opens the Sensor
parameters dialog.
NIBP start/stop Starts or stops an NIBP
measurement. The button
remains selected during a
measurement. To cancel the
measurement, select the
button again.
Zero all
1)
Zeroes all pressures
System setup... Opens the System setup
dialog.
Start/Standby... Opens the Start/Standby
dialog.
Home Returns to the main screen and
closes any dialog.
1)
This button only appears on the main menu bar
of the C700.
