Agent/xMAC parameter field
The Agent/ xMAC parameter field displays the
following additional values:
– xMAC – the MAC multiple calculated from the
current expiratory measured values and the
age-dependent MAC values
A Abbreviation for primary anesthetic agent (may
display Agent? during agent identification for
gas analyzers with automatic identification)
B Abbreviation for secondary anesthetic agent
(for gas analyzers with automatic identification)
C Abbreviation for "inspiratory"
D Inspired primary agent value – the level of
anesthetic agent in the airway during the
inspiration phase
E Inspiratory alarm limits for primary agent
F Abbreviation for "expiratory"
G Expired primary agent value – the level of
anesthetic agent in the airway during the
expiration phase
H Expiratory alarm limits for primary agent
I Expiratory alarm limits for secondary agent
J Expired secondary agent value – the level of
anesthetic agent in the airway during the
expiration phase
K xMAC multiple
L Inspiratory alarm limits for secondary agent
M Inspired secondary agent value – the level of
anesthetic agent in the airway during the
inspiration phase
N Age used to calculate xMAC (default age of 40
is the user has not entered a birth date for the
patient)
O xMAC label
Agent_xMAC_pbox_en.pdf
O2
4.4
0.0
in et
10.1
0.0
N2O
AGE 40 2.0
12.7
0.0
20.0
0.0
3.04
3.04
3.0 3.0
A B E FG CD H
IJKLMNO
