Agent/N2O parameter field
The Agent/N2O parameter field displays the
following additional values:
– Inspired N
2O (inN2O) – the level of N2O in the
airway during inspiration, taken as the minimum
value within the measurement interval
– End-tidal N2O (etN2O) – the highest level of
N
2O in the airway during the expiratory phase
within the measurement interval
A Abbreviation for primary anesthetic agent (may
display Agent? during agent identification for
gas analyzers with automatic identification)
B Abbreviation for secondary anesthetic agent
(for gas analyzers with automatic identification)
C Abbreviation for "inspiratory"
D Inspired primary agent value – the level of
anesthetic agent in the airway during the
inspiration phase
E Inspiratory alarm limits for primary agent
F Abbreviation for "expiratory"
G Expired primary agent value – the level of
anesthetic agent in the airway during the
inspiration phase
H Expiratory alarm limits for primary agent
I Expiratory alarm limits for secondary agent
J Expired secondary agent value – the level of
anesthetic agent in the airway during the
expiration phase
K etN
2O value – the highest level of N2O in the
airway during the expiratory phase within the
measurement interval
L Inspiratory alarm limits for secondary agent
M Inspired secondary agent value – the level of
anesthetic agent in the airway during the
inspiration phase
N inN
2O value – the level of N2O in the airway
during inspiration, taken as the minimum value
within the measurement interval
O N
2O label
Agent_N2O_pbox_en1.pdf
O2
4.4
0.0
in et
10.1
0.0
N2O
70 69
12.7
0.0
20.0
0.0
3.0 3.0
3.04
3.04
A B EFG
C
D
H
O LKJ NM I
