External devices – MEDIBUS.X devices
414 Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n
2 Press any button to activate a list of available
parameters. You can also select None to
remove any parameter from being displayed in
that space. The parameter selection MV auto,
RR auto and VT auto are unique because the
associated parameter set varies from device to
device. When the Vent parameter display
setting Auto is selected, the Cockpit pulls the
available parameter from the source device
according to the following priority list:
– MV auto: MVe, MV,MVi
– RR auto: RR, RRf, RRp
– VT auto: VTe, VTACH,VTi
3 Select the desired parameter in the list to assign
it to the button and to the Show all page.
4 Repeat steps 2 and 3 until the desired configu-
ration for the Show all page is completed.
Accessing parameter setup functions
You can configure the display of ventilation and
anesthesia parameters in the following tabs located
under the Ventilator or the Anesthesia
workstation tabs.
–Paw
–Vent
– CO
2 (when a ventilator is connected) or
CO
2/O2/ Agent (when anesthesia workstation is
connected)
1 Select Sensor parameters... from the main
menu bar.
2 Select the > Ventilator or the Anesthesia
workstation tab.
If you cannot see the tab, select the following
two symbols located in the upper right corner of
the dialog: symbol and the display filter
button.
3 Select either the Paw, Vent or CO
2 or CO2/O2/
Agent tabs to access the respective setup
pages.
NOTE
Depending on which devices are connected to the
Cockpit, two Ventilator tabs may be displayed.
The MEDIBUS.X Ventilator tab is the one that
has the message Medibus.X ventilator devices
displayed as a header on the various pages.
NOTE
Most setup functions described in the following ta-
bles are available under the Ventilator and the
Anesthesia workstation tabs. Exception where
a setup function is only available under one tab
are noted.
