Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 439
External devices – Evita 2D, Evita 4, Evita XL (Medibus)
Accessing the parameter setup functions
1 Select Sensor parameters... from the main
menu bar > Ventilator tab to access the
Ventilator page. If you cannot see the tab,
select the following two symbols located in the
upper right corner of the dialog: symbol and
the display filter button.
2 Select either the Paw or the Vent tabs to access
the respective pages.
Ventilator Paw setup functions
See page 439 for information on how to access this
page.
NOTE
Depending on which devices are connected to the
Cockpit, two Ventilator tabs may be displayed. If
you select the Ventilator tab and the selected
page has the message Medibus.X ventilator
devices displayed as a header, you have
selected the wrong Ventilator tab.
Selection Available settings Description
Paw scale 10, 15, 20, 25 (default), 30, 40, 50, 60, 70, 80,
100, 120 mbar
Determines the scale of the
displayed Paw waveform.
Parameter 1 Pmean, PEEP, PIP (default) Selects the primary
parameter in the Paw
parameter field.
Parameter 2 Pmean
(default), PEEP, PIP Selects the second
parameter in the Paw
parameter field.
Parameter 3 Pmean, PEEP (default), PIP Selects the third parameter
in the Paw parameter field.
Color Red, green, blue, yellow, light blue (default),
purple, orange, white.
Determines the color of all
ventilation parameter fields,
waveforms, and loops.
