SpO2 and pulse rate with Nellcor OxiMax MCable
278 Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n
Accessing the SpO2 settings
1 Select the SpO2 parameter field to select the
SpO2 page directly.
or
Select Sensor parameters... from the main
menu bar.
2 If you cannot see the tab, select the following
two symbols located in the upper right corner of
the dialog: symbol and the display filter
button.
The top portion of the page contains the Auto set
and Alarm buttons for configuring the alarm
functions. For detailed alarm setup information, see
"Configuring the alarm settings for a patient" on
page 125.
SpO2 parameter setup functions
All SpO2 setup functions take place in the SpO2
page.
Selection Available settings Description
Pulse tone
volume
Off, 5%, 10% (default), 20%,
30%, 40%, 50%, 60%, 70%,
80%, 90%, 100%
Sets the volume of the pulse tone.
Tone source ECG (default), SpO2 Selects the source of the pulse tone which
affects both the ECG and the SpO2
parameter field display (see page 277). For
the SpO2 selection, the higher the pitch of the
tone, the higher the SpO2 saturation
percentage.
Waveform size
[%]
10%, 20%, 30%, 40% (default),
50%, 60%, 70%, 80%, 90%,
100%
Sets the amplitude of the SpO2 waveforms.
If the waveform height exceeds the display
size of the channel, the waveform appears
clipped (without affecting the SpO2 signal
processing).
