Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 371
Scio Monitoring
O2/N2O parameter field
The O2 / N2O parameter field displays the following
additional values:
–Inspired N
2O (inN2O) – the level of N2O in the
airway during inspiration, taken as the minimum
value within the measurement interval
– End-tidal N2O (etN2O) – the highest level of
N
2O in the airway during the expiratory phase
within the measurement interval
A O
2 label
B N
2O label
C Abbreviation for "inspiratory"
D inO
2 (FiO2) value – the level of O2 in the airway
during inspiration, taken as the minimum value
within the measurement interval
E inN2O value – the level of N2O in the airway
during inspiration, taken as the minimum value
within the measurement interval
F inO2 (FiO2) alarm limits (displays crossed
triangle symbol when inO2 alarms are turned
off)
G Abbreviation for "expiratory"
H etO
2 value – the highest level of O2 in the
airway during the expiratory phase within the
measurement interval
I etN
2O value – the highest level of N2O in the
airway during the expiratory phase within the
measurement interval
J etO2 alarm limits (displays crossed triangle
symbol when etO2 alarms are turned off)
O2_N2O_pbox.pdf
25
O2
100
20
in et
30
100
10
N2O
70 69
A B C DE F G H I J
