Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 67
Operating concept
Filtering the parameter content
To filter the content of the displayed parameters,
use the display filter button which appears in
the following dialogs:
– Parameter field of the Trends/Data dialog (see
page 162).
– Sensor parameters dialog where it appears to
the right of the parameter tabs.
– Alarms dialog (see page 129).
– Setup page for configuring the trend pages
(see page 167).
The filter button toggles between an unfiltered and
filtered display. The filter is activated when the
display filter button appears on the light green
background. Any parameter that is not being
actively monitored is removed from the screen,
including parameter-specific setup buttons or tabs.
Selecting the button again changes the background
to dark green and deactivates the display filter. All
parameters, whether monitored or not, including
associated setup buttons or tabs are displayed.
Auto and manual display modes
The user interface has two display modes: Auto
view and manual view.
Auto view mode
Auto view mode is a plug-and-play concept where
the content of the main screen depends on the
connected parameter signals. For example, as
soon as an SpO2 MCable is connected, the
associated parameters become available for
display. When the MCable is disconnected, the
parameters are removed from the screen
automatically.
Manual view mode
In manual view mode, parameters for display can
be selected even if they are not yet connected. In
this mode, the parameter pick list in the Auto view
page (see page 74) contains all parameters. The
parameters that are not connected appear gray in
the parameter pick list. In addition, the display filter
button is deactivated.
To select the desired display mode
1 Select System setup... from the main menu
bar.
2 Select the Screen setup tab.
3 Select the Auto view tab located along the right
side of the System setup dialog.
4 Select the Auto or Manual button next to the
Display mode menu selection.
NOTE
The NIBP parameter is always displayed. The
M540 does not detect the connection status for
this parameter.
