Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 311
Invasive blood pressure (IBP)
Standard labels
The M540 detects the labels automatically from the
hemodynamic pod, provided a transducer is
connected. The M540 transfers the labels to the
Cockpit. You can also label pressure channels
manually.
The following table lists the available invasive blood
pressure labels.
IBP Labels
Label Pressure type Measured pressures Measurement range
ART Arterial blood pressure Systolic, diastolic, mean –50 to +400 mmHg
–6.6 to +53.3 kPa
LV Left ventricular blood
pressure
PA Pulmonary arterial blood
pressure
RV Right ventricular blood
pressure
CVP Central venous blood
pressure
Mean
CPP
1)
Cerebral perfusion pressure
RA Right atrial blood pressure
LA Left atrial blood pressure
ICP Intracranial pressure
Generic Labels
GP1 to GP4 Systolic, diastolic, mean
1)
The CPP value is only calculated when ICP and ART M pressure values are available.
