366 Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n
CO2 display
On the Cockpit, the CO2 display consists of:
–CO
2 parameter field
–CO
2 waveform
The Cockpit supports a configurable parameter
field for display of CO
2 that allows one of the
following displays:
–CO2 by itself (default)
–CO
2 with O2 (only for gas analyzers with O2
monitoring)
CO2 parameter field
The default CO2 parameter field displays the
current values for:
– Inspired CO
2 (inCO2) – the level of CO2 in the
airway during inspiration phase.
– End-tidal CO
2 (etCO2) – the level of CO2 in the
airway at the end of expiration.
– Respiratory Rate (RRc) – the patient’s
respiratory rate, derived from the etCO2 signal.
A etCO2 label
B etCO
2 value – highest level of CO2 in the airway
during the expiratory phase within the
measurement interval
C etCO2 alarm limits (displays crossed triangle
symbol when etCO2 alarms are turned off)
D inCO
2 label
E inCO
2 value – the level of CO2 in the airway
during inspiration, taken as the minimum value
within the measurement interval
F inCO2 alarm upper limit (displays crossed
triangle symbol when the inCO2 alarm is turned
off)
G RRc alarm limits (displays crossed triangle
symbol when RRc alarms are turned off)
H RRc parameter label
I RRc value – respiratory rate derived from the
CO
2 signal.
EtcO2pbox_en.pdf
27
0
21
etCO2
inCO2
RRc
70
20
30
5
4
A B CDEF
GHI
