Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 165
Trends/data dialogs
The layout of the graphical trends pages
The graphical trends pages share a common
layout. They contain up to four separate trend
windows. Each trend window can accommodate
the graphical trends of up to five selectable
parameters. For each parameter, the trend panel
also displays trend scales, units of measure, and
the parameter label.
The following diagram shows the layout of the
graphical trends pages.
A Trends tab
B Graph tab – accesses graphical trends
C Table tab – accesses the tabular trends
D Graph vitals tab – accesses the graphical
trends of a set of pre-configured trend
parameters.
E Ventilation / Anesthesia tab – accesses the
graphical trends of a set of pre-configured trend
parameters for critical care or anesthesia
ventilation.
F BIS tab – accesses the graphical trends for the
BIS VISTA device.
G Trend setup symbol for selecting up to five
parameters
H Scroll keys
I Print button
J Grids on/off button
K Graphs button
L View button for selecting how much time is
displayed
M Graphical trend panels
Directly below the trend windows is a time scale
that correlates to the selected interval.
023
Trends/Data
A
B
C
D
E
F
G
H
I
J
M
M
M
K
L
M
