Trends/data dialogs
Configuring the parameter content of the tabular trend
The following diagram depicts the setup page for
modifying the parameter content of the tabular
trend.
A Group of parameter buttons entitled ECG for
selecting ECG-related parameters
B Group of parameter buttons entitled Pressure
for selecting pressure-related parameters
C Group of parameter buttons entitled Vent
devices for selecting ventilation parameters
D Group of parameter buttons entitled Medibus.X
for selecting MEDIBUS.X parameters available
using the device connectivity option
E OK button
F Cancel button
G Clear all button – deselects any buttons that
are currently selected
H Select all button – selects all buttons at once
I Auto-sort button
J Window for sorting the parameters
automatically
K Group of parameter buttons entitled Other for
selecting miscellaneous parameters such as
SpO2, temperature, and so on
L Group of parameter buttons entitled CO
2 for
selecting for selecting CO2-related parameters
M Group of parameter buttons entitled More
devices for selecting additional parameters
To modify the parameter selection for a tabular
trend
1 Access the Trends > Table page (see
page 175).
2 Select the trend setup symbol at the
bottom of the tabular trend.
3 Use the display filter button (A) to toggle
between the filtered or unfiltered display. When
the button is on a light green background
only the buttons of the connected parameters
are displayed. When the symbol appears on a
dark green background, the buttons of all
parameters, whether monitored or not, are
displayed.
4 Select the Auto-sort button to sort the
parameter list according to the parameter
priority list in the Auto view setup page (see
page 67).
or
Select the parameters to display in the tabular
trend.
5 Select the OK button (D) to confirm the
selection and reconfigure the tabular trend.
Select the Cancel button (E) to exit the screen
without accepting the changes.
491
x
J
H
G
F
E
D
C
L
A
B
K
M
I
NOTE
Buttons with ellipses such as More ventilation...
or More gases... access additional parameters.
