Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 185
Calculations
Viewing the calculation results
The following diagram shows the Results page for
viewing hemodynamic, oxygenation, and
ventilation parameters.
A Calculations tab
B Parameters column
C Data column with reference values
D Data columns with date and time stamp
E Calculation tab (see page 183)
F Results tab
G Scroll bar
H Save button
I Setup button
Viewing and saving calculations
The Results page allows you to configure the
display and save calculations. You can save up to
50 calculations before they are overwritten on a
first-in first-out basis. The scroll bar (G) consists of
single and double arrow keys and a moveable bar.
The double arrows scroll through larger portions
than the single arrows. You can also drag the
navigation bar located between the arrow keys to
the desired location. The same page is also
available under the Hemo tab (see page 178).
028
