System configuration
448 Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n
Configuring parameters for display
Basically, the parameter selection window (D) of
the Auto view page controls where a parameter
appears on the screen. The window also controls
how a parameter is displayed (as a waveform
and/or as a parameter field), or if it is excluded from
display. To access this page, see page 444.
A Auto view tab
B Auto button
C Manual button
D Parameter selection window
The parameter selection window
The parameter selection window (D) in the Auto
view page determines where a parameter appears
on the screen and how it is displayed.
The selected display mode determines how the
parameter selection window behaves:
– If you select the Auto button (B) next to Display
mode, the parameter selection window
functions dynamically with the auto view setup
toolbar (see page 449). You can also determine
the content of the parameter list by using the
display filter button . When it appears on a
dark green background, all parameters are
displayed in the parameter selection window,
even if they are not connected. Parameters that
are not connected appear gray. However, as
soon as you connect a parameter, the
corresponding label appears black, and
occupies the assigned location on the screen.
When the display filter button appears on a light
green background, the parameter selection
window contains only connected parameters.
– If you select the Manual button (C) next to
Display mode, all parameters are listed. In this
case, the display filter button is deactivated.
If a parameter is not connected, the
corresponding label appears gray. However,
unlike in auto mode, the parameter label and/or
waveform occupies a space on the screen even
though it is not connected yet.
050
B
C
D
D
D
System setup
A
