BeneVision N Series Patient Monitor Operator’s Manual 8 - 5
8.5.2.2 System Responses at the BP10 after Pairing the BP10 and the Monitor
Once a BP10 is paired successfully with the monitor, the BP10 responds as below:
â– The symbol is changed to in the prompt message area.
â– The BP10 allows you to start or stop NIBP measurement by pressing the start or stop NIBP button on the
front panel of the BP10. But it does not allow you to change any settings.
8.6 Unpairing the BP10 and the Monitor
You can unpair the BP10 and the monitor either via the monitor or via the BP10.
8.6.1 Unpairing via the Monitor
To unpair the BP10 and the monitor, follow this procedure:
1. Select the Main Menu quick key → select Wireless Module from the Parameters column.
2. Select the desired BP10.
3. Select Remove.
Upon completion of unpairing, the message Disconnection Completed appears on the monitor screen.
8.6.2 Unpairing via the BP10
To unpair the BP10 and the monitor, press the MPAN button on the right panel of the BP10.
8.7 NIBP Measurement in Sequence or ABPM Mode
When a BP10 is paired with the monitor, you can perform NIBP measurements in sequence or ABPM mode. For
detailed information about NIBP measurement, see BP10 NIBP Module Operator’s Manual (PN:046-008269-00).
8.7.1 Performing NIBP Measurement in Sequence Mode
To perform NIBP measurement in sequence mode, follow this procedure:
1. Select the NIBP parameter area on the monitor screen to enter the NIBP menu.
2. Select the Sequence tab.
3. Set Interval and Duration for the desired measurement phases.
4. Select Start NIBP.
Once NIBP measurement is completed, the sequence mode, current measurement phase, interval, and
duration will be displayed on the monitor screen.
8.7.2 Performing NIBP Measurement in ABPM Mode
In ABPM mode, the NIBP measurements are automatically taken according to the configured intervals for the
day and the night.
To perform NIBP measurement in ABPM mode, follow this procedure:
1. Select the NIBP parameter area on the monitor screen to enter the NIBP menu.
2. Select the ABPM tab.
3. Set Start Time and Interval for the day and night.
4. Select Start NIBP.
Once NIBP measurement is completed, the ABPM mode and measurement values will be displayed on the
monitor screen.
