3 - 16 BeneVision N Series Patient Monitor Operator’s Manual
3.13.2 Changing Secondary Display Settings
See 3.8.3Adjusting the Screen Brightness for changing screen brightness for the secondary display.
See 39.8The Display Settings for setting the display contents of the secondary display.
For N22/N19, see 39.8The Display Settings for setting alarm indications for the secondary display.
3.13.3 Setting the ECG Waveform Size for the Independent External Display (for N17/
N15/N12)
For N17/N15/N12 monitors, if the independent external display is connected, you can set the speed and
amplitude scales of the ECG waveforms for displays of different dimensions to achieve the best display effect. To
do so, follow this procedure:
1. From the independent external display screen, select the Main Menu quick key → from the System
column select Maintenance → input the required password → select.
2. Select Display → select the Screen Size tab.
3. Select the screen size.
4. Set the speed and amplitude of the ECG waveform corresponding to one centimeter.
5. Restart the monitor.
NOTE
• The setting of Screen Size for the independent external display takes effect only after the monitor
restarts.
(1) the amplitude ECG waveform corresponding to one centimeter
(2) the speed of the ECG waveform corresponding to one centimeter
1
2
