BeneVision N Series Patient Monitor Operator’s Manual 3 - 19
3.15.3 Manually Starting Remote Screen
You can only start remote screens from the PC. To start a remote screen, follow this procedure:
1. Double-click the nView tool icon to run the nView tool.
2. If you are starting the remote screen for the first time, configure it first. For more information, see
3.15.4Configuring the Remote Screen.
3. Select the desired monitor:
a Select the Select Device tab.
b Select Refresh Device List.
c From the monitor list, select the desired monitor.
4. Select the nView Tool tab → Start Remote Screen.
After the remote screen is started, the remote screen icon displays on the taskbar.
3.15.4 Configuring the Remote Screen
To configure the remote screen, follow this procedure:
1. Double-click the nView tool icon to run the nView tool.
2. Select the Setup tab to set the following parameters:
â—† Language: the language of the remote screen and nView Tool user interface.
â—† Local IP Address: the IP address of the PC. The PC must be connected to the same LAN as the
monitor.
â—† Remote Screen Port: used as the port for TCP service and shall not conflict with other applications
runs on the PC.
â—† Monitor Multicast Address: usded to discover the monitor.
â—† Start nView Screen When Monitor Online: If this switch is on, the remote screen automatically starts
when the monitor is connected to the network.
â—† Shut Down PC When Monitor Shutdown: If this switch is on, the PC automatically shuts down when
the monitor shuts down.
â—† Number of Remote Screens: selects the number of displays used for nView. When the PC connects
multiple displays, the maximum number of displays for nVeiw is 3.
â—† Remote Screen X Position: selects where the remote screen is displayed. For example, if Remote
Screen 1 Position is set to Display 3, remote screen 1 will be on display 3. To identify the displays,
select Identify Display.
â—† Full Screen: if this switch is on, the remote screen displays in full size. If this switch is off, you can zoom
in or out the remote screen. To achieve optimal full screen, setting the display resolution to
1920×1280 is recommended.
â—† Remote Screen Always on Top: if this switch is on, the remote screen is always on the frontground..
• If the Remote Screen Always on Top switch is off, the remote screen may be covered by other
applications. If you need constant access to the patient data, make sure the remote screen is always
in the foreground.
3.15.5 Setting the ECG Waveform Size for the Remote Screen
For displays of different dimensions, you can set the speed and amplitude of the ECG waveforms for the remote
screen to achieve the best display effect. To do so, follow this procedure:
1. From the remote screen, select the Main Menu quick key → from the System column select Maintenance
→ input the required password → select.
2. Select Display → select the Screen Size tab.
3. Set the speed and amplitude of the ECG waveform corresponding to one centimeter.
