A.10.5 Interface Specifications of the N17/N15/N12/N12C
A.11 Signal Outputs Specifications
AC power input 1
Network connector N17: 2, standard RJ45 connectors (one on the iView module)
N15/N12/N12C: 1, standard RJ45 connector
USB connector N15/N12/N12C: 4, USB 2.0
N17: 8, USB 2.0, 4 on the iView module
Satellite module rack (SMR)Dock
connector
1 (For N17/N15, it connects the SMR, N1 Dock, or T1 Dock. For N12/N12C, it
connects the N1 Dock or T1 Dock)
Video output connector N17: 2 (one for the iView system)
N15/N12/N12C: 1
Nurse call connector 1, standard BNC
Equipotential grounding terminal 1
Auxiliary Output
Standard Meets the requirements of IEC 60601-1 for short-circuit protection and
leakage current
ECG Analog Output
Bandwidth
(-3dB; reference frequency: 10Hz)
Diagnostic mode: 0.05 to 150 Hz
Monitor mode: 0.5 to 40 Hz
Surgical mode: 1 to 20 Hz
ST mode: 0.05 to 40 Hz
Maximum QRS delay 25 ms (in diagnostic mode, and non-paced)
Gain (reference frequency 10Hz) 1V/mV (±5%)
Pace enhancement Signal amplitude: V
oh
≥2.5V
Pulse width: 10ms±5%
Signal rising and falling time: ≤100µs
IBP Analog Output
Bandwidth (-3dB; reference
frequency:1Hz)
0 to 40 Hz
Maximum transmission delay 30 ms
Gain (reference frequency 1 Hz) 1 V/100 mmHg, ±5%
Nurse Call Signal
Amplitude High level: 3.5 to 5 V, ±5%, providing a minimum of 10 mA output current;
Low level: < 0.5 V, receiving a minimum of 5 mA input current.
Rising and falling time ≤1 ms
Defib Sync Pulse
Output impedance ≤100 ohm
Maximum time delay 35 ms (R-wave peak to leading edge of pulse)
Amplitude High level: 3.5 to 5 V, ±5%, providing a maximum of 10 mA output current;
Low level: < 0.5 V, receiving a maximum of 5 mA input current.
Pulse width 100 ms ±10%
maximum rising and falling time 1 ms
Alarm output
