34 - 16 BeneVision N Series Patient Monitor Operator’s Manual
34.5.3.5 Closing the CPR Dashboard
CPR Dashboard automatically closes when you exit the rescue mode. In the rescue mode, if you want to close the
CPR Dashboard, choose any of the following ways:
■ Select the exit key at the top right corner of the CPR Dashboard.
■ Select the Main Menu quick key → from the CAA column select Exit CPR Dashboard.
■ Select the CPR parameter area, from the CPR menu, select Exit CPR Dashboard.
34.5.4 Exit the Rescue Mode
To exit the rescue mode, choose either of the following ways:
■ Select the Exit Rescue Mode quick key.
■ Select the Main Menu quick key → from the Alarm column select Exit Rescue Mode.
34.6 ECG 24h Summary
The ECG 24h Summary provides ECG statistics of the current patient over the latest 24 hours. You can view the
following information through the ECG 24h Summary:
■ Heart rate statistics
■ Arrhythmia event statistics
■ QT/QTc measurement statistics
■ Maximum and minimum ST statistics of each lead
■ Pacer statistics
■ Typical ECG strips
NOTE
• The ECG 24h Summary is intended for the current patient. It is not intended for discharged patients.
• Pacer statistics is intended for paced patients.
• Patient data is saved, collected and displayed together in the ECG 24h Summary. Data displayed in
the ECG 24h Summary is not recalculated.
• If BeneView T1 is used to monitor a patient, when BeneView T1 is connected with the host monitor,
data sent to the host monitor is not included in the ECG 24h Summary.
• A license is required for the ECG 24h Summary function.
34.6.1 Viewing the ECG 24h Summary
To view the ECG 24h Summary, choose either of the following ways:
■ Select the ECG 24h Sum quick key.
■ Select the Main Menu quick key → from the CAA column select ECG 24h Summary.
34.6.2 Selecting Typical ECG Strips
The Typical Strips area displays ECG strips of the following situations:
■ Maximum heart rate
■ Minimum heart rate
■ Four arrhythmia events
You can select a typical ECG strip of each situation. For example, to select the typical ECG strip of asystole, follow
this procedure:
1. Select the currently displayed asystole strip.
2. From the popup strips, select the desired strip as the typical strip of asystole.
