A - 10 BeneVision N Series Patient Monitor Operator’s Manual
A.14 MPAN Specifications
A.14.1 MPAN Technical Specifications
A.14.2 MPAN Performance Specifications
A.14.2.1 System capacity and resistance to wireless interference
Meets the following requirements:
■ The distinct vision distance between the monitor and the BP10 or the TM80: ≥ 5 m.
■ Bluetooth communication does not interrupt.
■ The total delay of data transmission from the TM80 or BP10 to the monitor: < 2 s.
Testing conditions are as follows:
■ Five pairs of monitors and telemetry devices (TM80 or BP10) can communicate in a 10 m
2
space.
■ The monitors communicating with the CMS via Wi-Fi.
■ The distance between the interfering devices and the monitor is greater than 20 cm. The interfering
devices include but are not limited to: Bluetooth devices, remote controllers, microwave ovens,
interphones, network devices, cordless phones, and ESU equipment.
A.14.2.2 Bluetooth network stability
Meets the following requirements:
■ The distinct vision distance between the monitor and the BP10 or the TM80: ≥ 5 m.
■ The data loss percentage of bluetooth communication over a 24-hour period: < 0.1%.
Testing conditions are as follows:
■ Five pairs of monitors and telemetry devices (TM80 or BP10) can communicate in a 10 m
2
space.
■ The monitors communicating with the CMS via Wi-Fi.
Modulation mode GFSK
Operating frequency 2402 MHz to 2480 MHz
Channel spacing 2MHz
Wireless baud rate 1 Mbps
Output power ≤2.5mW
Data security Private protocol
