A - 4 BeneVision N Series Patient Monitor Operator’s Manual
A.4 Power Supply Specifications
A.4.1 External Power Supply Specifications
A.4.2 Battery Specifications
A.4.2.1 N22/N19 Battery Specifications
PiCCO module Temperature (ºC) 10 to 40 -20 to 60
Relative humidity
(noncondensing) (%)
15 to 75 10 to 90
Barometric (mmHg) 427.5 to 805.5 120 to 805.5
ScvO
2
module Temperature (ºC) 10 to 40 -20 to 60
Relative humidity
(noncondensing) (%)
15 to 75 10 to 90
Barometric (mmHg) 427.5 to 805.5 120 to 805.5
rSO
2
module Temperature (ºC) 16 to 32 -20 to 70
Relative humidity
(noncondensing) (%)
20 to 80 10 to 95
Barometric (mmHg) 522 to 805.5 435.7 to 822
Components Item Operating Condition Storage Condition
Line voltage 100 to 240 VAC (±10%)
Input current N22/N19: 2.8 to 1.6 A
N17/N15/N12/N12C: 2.0 to 0.9 A
Frequency 50/60 Hz (± 3 Hz)
Battery type Rechargeable lithium-Ion battery
Voltage 11.3 VDC
Capacity 5600 mAh
Run time At least 1 hour when the monitor is powered by a new fully-charged battery
at 25 ºC±5 ºC and works continuously at the following conditions:
• The monitor is configured with a 12-lead ECG, Resp, SpO
2
, 4-channel IBP, 2-
channel Temp, CO
2
, C.O.
• NIBP module set at an interval of 15 minutes.
•Wi-Fi is enabled.
• The screen brightness is set to the factory default.
Shutdown delay: at least 15 minutes after the low battery alarm first occurs
Charge time For a new battery:
5 hours to 90% when the monitor is off.
9 hours to 90% when the monitor is on.
